Vertical Hi-Stack Fan Coils

Specifications

Master Spec:
9 Pages

Vertical Stack

Updated: June 2013

Vertical Hi-Stack Fan Coils, Entire Family

Hideaway Model

Back-to-Back Models

Master/Slave Models

Miscellaneous

Dimensional Drawings

Return Air Grille

Valve Packages

General Data:
3 pages

Updated: Jun 2012

Components:
2 pages

Updated: Jun 2012

Basic Valve Packages

Pre-assembled, factory installed valve packages

V-B1

• Ball valve on return

• Ball valve on supply

V-B2

• Manual circuit setter on return

• Ball valve on supply

V-B3

• Auto circuit setter and ball valve on return

• Ball valve on supply

V-B4E

• Ball valve on return

V-B5E

• Manual circuit setter on return

• 2-way electric valve and ball

V-B6E

• Auto circuit setter and ball valve on return

• 2-way electric valve and ball valve on supply

V-B4M

• Ball valve on return

• 2-way electric valve and ball valve on supply

V-B5M

• Manual circuit setter on return

• 2-way electric valve and ball valve on supply

V-B6M

• Auto circuit setter and ball valve on return

• 2-way electric valve and ball valve on supply

V-B7E

• Ball valve on return

• Balance fitting in bypass

• 3-way electric valve and ball valve on supply

V-B8E

• Manual circuit setter on return

• Balance fitting in bypass

• 3-way electric valve and ball valve on supply

V-B9E

• Auto circuit setter and ball valve on return

• Balance fitting in bypass

• 3-way electric valve and ball valve on supply

V-B7M

• Ball valve on return

• Balance fitting in bypass

• 3-way electric valve and ball valve on supply

V-B8M

• Manual circuit setter on return

• Balance fitting in bypass

• 3-way electric valve and ball valve on supply

V-B9M

• Auto circuit setter and ball valve on return

• Balance fitting in bypass

• 3-way electric valve and ball valve on supply

Deluxe Valve Packages

Pre-assembled, factory installed valve packages

V-D4E

• Ball valve and union on return

• 2-way electric valve, ball valve, union and strainer on supply

V-D5E

• Manual circuit setter and union on return

• 2-way electric valve, ball valve, union and strainer on supply

V-D6E

• Auto circuit setter, union and ball valve on return

• 2-way electric valve, ball valve, union and strainer on supply

V-D4M

• Ball valve and union on return

• 2-way electric valve, ball valve, union and strainer on supply

V-D5M

• Manual circuit setter and union on return

• 2-way electric valve, ball valve, union and strainer on supply

V-D6M

• Auto circuit setter, union, and ball valve on return

• 2-way electric valve, ball valve, union and strainer on supply

V-D7E

• Ball valve and union on return

• Balance fitting in bypass

• 3-way electric valve, ball valve, union and strainer on supply

V-D8E

• Manual circuit setter and union on return

• Balance fitting in bypass

• 3-way electric valve ball valve, union and strainer on supply

V-D9E

• Auto circuit setter, union and ball valve on return

• Balance fitting in bypass

• 3-way electric valve, ball valve, union and strainer on supply

V-D7M

• Ball valve and union on return

• Balance fitting in bypass

• 3-way electric valve ball valve, union and strainer and supply

V-D8M

• Manual circuit setter and union on return

• Balance fitting in bypass

• 3-way electric valve, ball valve, union and strainer on supply

V-D9M

• Auto circuit setter, union and ball valve on return

• Balance fitting in bypass

• 3-way electric valve, ball valve, union and strainer on supply

Electric Heat Sub-Assemblies

Electric Heat Control Packages

Standard Control Packages

Line Voltage Control Packages

Miscellaneous Control Packages

General Schematics
